Technical Data Sheet - IPM2 60Hz Relay

The Ampcontrol IPM2 60 Hz Relay (Version IPM V2.0) is an intelligent protection relay based on microprocessor technology. All of the tripping logic and outlet control is performed by the microprocessor, so that virtually no external control is required. The IPM2 Relay provides the necessary functions required for protecting electrical outlets supplying underground mining machinery, powered by reeling or trailing cables, in the metalliferous industry.

User Manual - IPM2 60Hz Relay

The Ampcontrol IPM2 60 Hz Relay (Version IPM V2.0) is an intelligent protection relay based on microprocessor technology. All of the tripping logic and outlet control is performed by the microprocessor, so that virtually no external control is required. The IPM2 Relay provides the necessary functions required for protecting electrical outlets supplying underground mining machinery, powered by reeling or trailing cables, in the metalliferous industry.

User Manual - IPS Relay

The Ampcontrol Integrated Protection Solution (IPS) Relay is an intelligent protection solution based on microprocessor technology.

Application Note - Rockstarter Fail to Close Update

To date, there have been a few occurrences of Rockstarter’s experiencing fail to close faults on contact closure/outlet starts. Ampcontrol has investigated these occurrences over time and have devised a number of improvements to help mitigate future FTC occurrences.

Software Update Application Note - PIP - Protection Interface Platform

Ampcontrols Protection Interface Platform (PIP) has undergone numerous software updates over the years since its release, incorporating upgrades and improved functionality. Originally the software updates were implemented in a way that required Ampcontrol engagement to be able to undertake the process. To improve this, the system software and Operating System (OS) were both overhauled in the V3.0 release to enhance user experience. As part of the overhaul, the internal HDD partition structures needed to be altered.

Overland Conveyor Tracking Switch Termination Board

The Ampcontrol iMAC Tracking Switch termination board is designed for use in overland conveyor systems. It provides 5 digital inputs for facilitating belt tracking controls such as belt drift, belt wander, belt tear and bypass function.

Outlet Module 1000V VSD

Ampcontrol outlet module consists of a variable speed drive, protection electronics and switchgear for the operation of 1000V loads that require variable speed operation.

IMAC REMOTE KEYPAD (IRK)

The iMAC Remote Keypad is used when the iMAC Controller is installed in such a way that renders its own keypad inaccessible. For example, this would allow the iMAC Controller to be installed in a flameproof enclosure with its display visible through a window. The iMAC Remote Keypad can then be mounted outside of the enclosure, in the hazardous area.

Techical Datasheet - Pullcable Wedge Clamp

Intrinsically Safe Certified UPS

The Ampcontrol Exia / Exib Intrinsically Safe Certified UPS (Uninterruptible Power Supply) provides safe, reliable power in the most demanding environments. Certified for Group I Coal Mining hazardous area applications with Group II and Group III applications possible.

Intrinsically Safe BEV Battery System

The Ampcontrol Intrinsically Safe BEV Battery System allows BEV integrators to access a fully compliant intrinsically safe power source for their vehicles.

Inherently Safe UPS

The Ampcontrol Inherently Safe UPS provides safe, reliable power in the most demanding environments. With a variety of enclosure options available, this Inherently Safe UPS can be adapted to suit a wide range of usage applications where reliable power is required to support critical systems.

Ampcontrol Inherently Safe Portable Power Supply

The Ampcontrol Inherently Safe Portable Power Supply provides safe, reliable power in the most demanding environments. With a variety of enclosure options available, the inherently safe portable power supply can be adapted to suit a wide range of usage applications where reliable power is required to support critical systems.

Industrial BEV Conversion Partner

Ampcontrol offers a complete suite of Battery Electric Vehicle (BEV) components, custom design/manufacturing, integration support and lifetime support/servicing for a wide range of industrial BEVs.
